Selection of polyurethane equipment

Mudboard production can choose mudboard two-component low-pressure foaming machine, mudboard two-component high-pressure foaming machine, the machine picture is as follows:

二组份低压发泡机

Clay with two components of low pressure foaming machine is liquid polyols and isocyanates two components of the raw materials respectively stored in two material storage tank, by two rotary precision gear metering pump to the mixed system, the pressure under the action of mixing head open, two components were injected into the small in the mixing chamber, a mixing blade high speed stirring and mixing effect, make the material liquid evenly, to form the required product.

Application: this machine is suitable for producing polyurethane clay board, imitation wood products and so on.

Equipment technical parameters:


unit type

Flow rate (g/s)

LXPU-RY2-65

16-65g

LXPU-RY2-120

26-120G

二组份高压发泡机

Clay with two components of high pressure foaming machine is liquid polyols and isocyanates two components of the raw materials respectively stored in two material storage tank, with two rotating axial plunger metering pump (radial) sent to the mixed system, under the action of hydraulic mixing head open, two components was injected into the small mixing chamber with a high speed, high speed collision and mixing effect, make the material liquid evenly, mixing effect is good, no clean, stable performance, easy operation, achieve the goal of high production efficiency and environmental protection.

Application: this machine is suitable for producing polyurethane clay board, imitation wood products and so on.

Technical parameters of equipment:


unit type

flow rate (g/s)

LXPU-H2-L15

55-260
